No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

2Ah

Standard discharge(0.2C5A)after standard charge

2

Nominal Voltage

14.4V

Mean Operation Voltage

3

Charging limit voltage

16.8V

Discharge Cut-off Voltage

4

Discharge cut-off voltage

11V

5

Internal Impedance

≤180mΩ

6

Standard charge current

0.4A

7

Max. Charge current

1A

8

Standard discharge current

0.4A

9

Max.continuous discharge current

14A

10

Cycle life

500 times

11

Operation Temperature Range

Charge:0~45℃

60+/-25%R.H. Bare Cell

Discharge:-20~60℃

12

Storage Temperature Range

Less than 1 year:-20~25℃

60+/-25%R.H. at the shipment state

Less then 3 months:-20~40℃

13

Weight

Approx 260g

14

Dimension

50*76*126mm
