Rechargeable Lifepo4 100AH Battery Lifepo4 12V For Ship RV Backup Power
Rechargeable Lifepo4 100AH Battery Lifepo4 12V For Ship RV Backup Power
- Model：SJW-12100
- Specification：23140160-4S2P-12.8V-100Ah
- Voltage & Capacity：12.8V100Ah
- Finished product Size：328*172*215mm
Electrical Characteristics | Nominal Voltage | 12.8v |
Nominal Capacity | 100Ah @ 0.2C | |
Energy | 1280Wh | |
Internal resistance | ≤45mΩ | |
Cycle Life | >2000 cycles @ 0.2c charge/ discharge at 100%DOD,End of life 80% capacity | |
Months Self discharge | ≤3.5% per month at 25ºC | |
Standard Charge | Charge voltage | 14.6±0.2V |
Charge Mode( CC/CV) | At 0ºC~45ºC temperature, charged to 14.6v at constant current of 0.2C5A, and then, changed continuously with constant voltage of 14.6v until the current was not more than 0.02C5A | |
Charge current | 20A | |
Max.Charge current | 50A | |
Standard Discharge | Discharge current | 20A |
Max.continuous current | 100A | |
Max. Pulse current | 200A (<3S) | |
Discharge cut-off voltage | 10.0V | |
Environmental | Charge Temperature | 0ºC to 45 ºC |
Discharge Temperature | -20ºC to 60 ºC | |
Storage Temperature | 0ºC to 45 ºC | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | IFR32700 N60,4S17P |
Plastic Case | ABS | |
Dimension (L*W*H*TH) | 328*172*215*220mm | |
Weight | Approx. 13.1KG | |
Terminal | M8 |
Battery Details
Customize Bluetooth Function
Battery Connection
Why Is Saijowo 12V 100Ah Lifepo4 Battery The best-selling On The Market?
Saijowo 12V lithium batteries feature in large capacity, high discharge power, fast charging, long cycle life, and high stability. This lithium battery has an 80% discharge depth. Compared with other li-ion chemicals, an important advantage is its thermal and chemical stability, thereby improving the safety of batteries. By combining with LiFePO4, this product can undergo more stable redox reactions and faster ion migration. Another is that it provides a longer cycle life. It has a very constant discharge voltage and can remain stable until the battery is depleted. This allows the battery to provide almost all power before discharge, and can greatly simplify or even eliminate the need for voltage regulation circuits. The back of the battery has impact resistance and has been tested to withstand severe external impacts without explosion.
Advantages of Lifepo4 Battery VS Lead Acid Battery:
Capacity: the discharge curve of lifepo4 battery is flat, and 90% capacity utilization can be maintained at 12V, while the lead-acid battery is only 50%;
Weight: the weight of lifepo4 battery is only 1/3 of the lead-acid battery of the same specification;
Cycle Life: Lifepo4 battery has more than 3000~4000 cycles, and the service life can be 5~10 years.
Our Services:
1. Custom Battery Solution
We can customize everything for you according your ideas, including Dimension, Color, Housing, Logo, Bluetooth, Heating, GPS, Fuel Gauge, etc.
2. Quality Assurance Service
Every battery will be tested before shipping and we offer 3-5 years warranty for all lifepo4 batteries.
Fast Production:
Lead time: 10 days for samples
20 days for mass production order
Features:
Small size, long lifespan, light weight, multiple cycles
